5 Most Common Problems with John Deere 185 Hydro

The John Deere 185 hydro is a tractor with an output of around 17 HP. A single-cylinder gasoline Kawasaki FC540V engine powered this lawn tractor.

Electrical issues with the John Deere 185 Hydro include an unresponsive starter. It frequently chokes the fuel filter and occasionally stalls and stops the engine. Sometimes the cutting deck of the mower get clogged, leaving the grass unmowed.

All of these issues will be covered in this essay, along with the appropriate remedies. The JD 185 Hydro’s actual owners will also give you a rundown of the vehicle. Hang tight, then!

Problems and Solutions at a Glance:

Problems with John Deere 185 HydroSolutions
1. The engine not startingDrain old fuel and add fresh.
2. Engine overheatsReduce the load and keep blocked components clean.
3. Faulty spark plugInspect the spark and replace any damaged spark.
4. The starter does not runLocate and replace any blown fuses, and check the battery’s charge.
5. Vibration issue Check and change the worn belt or replace the damaged blades

5 Common Problems with John Deere 185 Hydro and Their Possible Solutions:

The John Deere 185 hydro is a very impressive piece of equipment. However, you could still run into some typical issues with it. Here are some John Deere 185 hydro issues and solutions.

1. The Engine Not Starting

A problem with the fuel system is the most common reason for not starting an engine.

Moreover, a filthy carburetor, a dirty air filter, a dead battery, a broken safety switch, poor spark plugs, or a broken ignition switch might all prevent the John Deere lawn 185 hydro engine from starting. An issue might possibly cause your starting issue with the charging system or ignition coil.

The Fix:

Fresh gasoline should be added to your fuel tank. The shelf life of gas is only 30 days before it starts to degrade and lose its effectiveness. Use gasoline as soon as possible. The fuel must be stabilized with a fuel additive if it won’t be used within 30 days.

Replace a severely corroded or filthy spark plug with a new one. Make sure to space them in accordance with the recommendations of your manufacturer.

For cracks, check the vacuum fuel pump. If you see gasoline leaking from the fuel pump or cracks in the pump, the pump will no longer function as intended. It must be swapped out.

By disassembling the carburetor and using cleaner to clean it, including the float bowl and needle, you may clean the carburetor.

2. Engine Overheats

If your JD 185 hydro lawnmower overheats, it may initially output less than usual.

Whether you observe a change in the power of your tractor, stop as soon as you can and turn the engine off to see if the mower is overheating due to overload, low engine oil, blocked cooling fins, clogged air cleaners, intake screens, or air pathways, or clogged cutting decks.

The Fix:

Reducing the load and keeping blocked components clean are the first things you should do. Clean the clogged components if the air intake screen is blocked. Fairly regularly, change the engine oil. check the bearings’ internal clearance.

3. Faulty Spark Plug

Either the spark plug or the spark plug connection may be defective. A plug that is too unclean might foul out, which could cause your engine to misfire.

Check your spark plug, which you should remove, for debris, carbon buildup, or a broken porcelain insulator. A spark plug gap can be a sign of a dead engine

The Fix:

Install a fresh spark plug in place of a severely corroded or filthy one. Make sure to space them in accordance with the recommendations of your manufacturer. Adjust spark plug gap.

If you discover that your spark plug is in good shape but has a filthy tip, clean it with a wire brush so you may reuse it.

4. The Starter Does Not Run

The JD 185 that the starter uses is another frequent issue that you could run into.

This might happen due to blown fuses, badly corroded battery terminals, low-voltage batteries, damaged battery cells, and situations where the cable and battery terminal are not in touch.

The Fix:

First, test the battery. Before checking the starter, you should check the battery because it powers the starter and if the battery is dead, the starter won’t work. Check the connectors for corrosion. If in doubt, you may verify the power output with a battery meter.

It’s also possible that a fuse has blown if the battery is producing power and your connections to the starting and starter relay are strong.

5. Vibration Issue

The vibration of a John Deere 185 hydro lawn mower might be caused by worn belts. There are further causes as well, such as a defective clutch, imbalanced mower blades, broken drive sheaves, or debris building up in your mower.

The Fix:

Your mower may vibrate as a result of a worn deck belt with additional slack. For wear indications, check your belt. Change a mower deck belt that is worn.

Check the bushings and connections if your lawn mower has a manual clutch that employs belts and pulleys. The balance of your blade may be checked with a blade balancer.

If your spindle housing has a faulty bearing, the blade may wander about more than usual. To protect your hands from the jagged blade edges while checking for faulty bearings, you should wear a sturdy pair of work gloves.

What Majority of the Users Feel?

The tractor’s specs might help you decide if the item fulfils your wants and requirements. A Sundstrand hydrostatic-style gearbox was included with the John Deere 185 model.

The tractor only had two gears: forward and reverse. Only 2.2 liters of fuel could be carried on the 185. Most of the clients are happy with its performance.

JD 185 Hydro price is fair. The tractor has a 38’ or 42″ deck and a 17hp Kawasaki engine. The Kawasaki engine is in excellent condition and requires no excessive oil. The hydro system functions very well. Sometimes there is smoke which is considerable.

In addition, customers who purchase the used Hydro 185 do not regret their decision.

Frequently Asked Questions

When was the John Deere 185 Hydro manufactured?

From 1986 until 1990.

What type of mowing deck does a John Deere 185 Hydro have?

There were two different rear deck sizes for the John Deere 185: 38 and 46 inches.

What type of engine is the John Deere 185 Lawn Tractor equipped with?

The John Deere 185 lawn tractor has a 17 HP Kawasaki 534cc 1-cylinder gasoline engine.

Final Thoughts

The John Deere 185 hydro are good machines, in my opinion, after giving them careful consideration based on my study. Particularly if you purchase models that are the second generation.

The engine problem, however, generally requires costly repairs. I encourage you to absolutely go for it if the John Deere’s better features appear worthy to you.
